Building Specifications

Building Specifications

Developer
Extell Development Company

Architect
Skidmore, Owings & Merrill

Floor Plates (Approx.)
22,500 rentable square feet (“RSF”)

Slab to Slab Heights (Approx.)
Floors 22 -­ 32: 13’ 6”
Floors 33 -­ 34: 16’ 0

Window Dimension
Floors 22 -­ 32: 4’8” module with 9’ 6” glass
Floors 33 -­ 34: 4’8” module with 12’ 2” glass

Curtain Wall Dimension
4’8” planning module.

Air Conditioning
Tenant-­controlled, water‐cooled seventy (70) ton DX VAV air conditioning units on each floor. Closed loop system, twenty (20) tons of condenser water capacity available per floor for Tenant’s supplemental use.

Heating System
Perimeter steam heat via fin tube supplied from Con Edison.

Electrical Services
Up to 6.5 watts/RSF connected load available for tenant use.

Telecommunications
Time Warner Cable and Verizon

Emergency Power
Two (2) 1500 KW generators for life safety and critical building functions. 450 KW of capacity allocated to serve additional tenant needs (subject to change). Roof space available for two (2) future Tenant generators.

Security
24/7/365 Security Command Center.
State‐of­‐the‐Art Access Control: The Building will be equipped with a control system featuring iris scanning technology and linked to the destination dispatch elevator system.

Parking
Secure, on-­‐site valet parking.
